Air Source Heat Pump for swimming pool is more and more popular, as it’s environmental friendly, high efficiency, economic advantage and easy to operation & maintenance. There are some notes for the air source heat pump installation, to guarantee the heat pump have ideal performance.
The heat pump will work properly in any desired location as long as the following three factors are present:
The air source heat pump should be installed in a place with outdoor ventilation and easy maintenance. It should not be installed in a small space with poor air; at the same time, the unit should keep a certain distance from the surrounding area to keep the air unobstructed, so as not to reduce the heating efficiency of the unit.
The following notes are usually recommended in the installation of the air source heat pump:
1. Install the air source heat pump pool unit downstream of all filtration units and pool pumps, and upstream of all chlorine generators, ozone generators, and chemical disinfection.
2. Under normal circumstances, the air source heat pump swimming pool unit should be installed within 7.5 meters from the swimming pool, and if the swimming pool water pipe is too long, it is recommended to pack a 10mm thick insulation pipe, so as to avoid insufficient heating due to excessive heat loss of the equipment;
3. The design of the waterway system needs to install a live connection or flange on the inlet and outlet water of the heat pump for drainage in winter, and it can be used as an inspection port during maintenance;
4. Shorten the water pipeline as much as possible, avoid or reduce unnecessary pipeline changes to reduce the pressure drop;
5. The water system must be equipped with a pump with appropriate flow and head to ensure that the water flow meets the needs of the unit.
6. The water side of the heat exchanger is designed to withstand the water pressure of 0.4Mpa (or please review the manual of the equipment). To prevent damage to the heat exchanger, do not use overpressure.
7. Please follow the installation & maintenance manual of the equipment for other notes.
GREATPOOL, as one professional factory and supplier of air source heat pump, supply various kinds of air source heat pump for swimming pool, such as the DC INVERTER series, mini serious and conventional serious.
GREATPOOL always treat product quality as the first priority, all the manufacturing and quality control are implemented based on ISO9001 & 14001 standard.
GREATPOOL, as one professional swimming pool & SPA equipment supplier, are ready to supply our product & service to you.
