* Description of the Ozone Gernerator
Ozone generator is mainly used in dedicine, water, pure water, mineral water, secondary water suply, swimming pool, acuaculture water, food and beverage industries such as water disinfection essence processing, and chemical industry, papermaking industry such as degreasing, bleaching, nleaching, for life, industry, hospital sewage treatment (sterilization, remove BOD, COD, ect.), as well as the life sewage, industrial cooling water reuse treatment, etc.
* Specification of the Ozone Generator
|
Ozone generator |
|||||
|
Model No. |
Size:L*W*H/cm |
Ozone output |
Voltage |
Weight/kg |
Power/w |
|
HY-013 |
80x55x130 |
80g/h |
220v 50hz |
40 |
1000 |
|
100g/h |
60 |
1300 |
|||
|
120g/h |
65 |
1500 |
|||
|
HY-004 |
32x25x82 |
5g/h |
11 |
160 |
|
|
10g/h |
13 |
180 |
|||
|
HY-003 |
40x30x93 |
20g/h |
25 |
380 |
|
|
40g/h |
30 |
400 |
|||
|
Air source |
Oxygen:80-100mg/L Air:15-20mg/L |
||||
* How the Ozone Generator system works?
Oxygen in the ambient air through a high voltage discharge to produce ozone. This activated oxygen is injected into the pool's circulation system, to make the water-oxidizing bacteria, viruses, fats, urea and other organic matter to improve, and removing turbidity, and make the water meet the clear and clean. FANLAN OZONE system only a small amount of maintenance processes, and can underideal conditions to monitor the desired pH value and free of chemical elements. Which provides health, clear water quality and the most comfortable swim in a sense.
* Advantages
1). Adopt standard high-frequency, high-voltage switching Power Supply with the functions of automatic frequency and width modulated, fault self-detecting, high efficiency, and so on.
2). Automatic control, and randomly set the treatment time.
3). Use the imported material of enamel pipe, whose outside is stainless steel discharge electrodes.
4). Dual-cooled technology: water-cooling, air cooling.
5). Optimum Air source system configuration.
6). Imported power core assembly, digital control power technology, with the function of constant pressure, frequency converter and pressure boost.
7). Work for 24 hours without a break.
8). Best match of special power supply and discharge tube.
9). Adopt Soft-switching Technique, with the efficiency reaches above 95%.
10). With the large amount of ozone it produced, high concentration up to 80-130MG/L.
